We have a wide variety of castor sales, and the order of the same day can be sent as soon as possible.

Heavy Duty Swivel Castors with Total Brake 4 Inch Load 270kg Elastic Polyurethane Wheel

Heavy Duty Castors - Total Lock Castors
Castor Number:
WAPB100H40UHDX
Availability:
In Stock
Heavy Duty Swivel Castors with Total Brake 4 Inch Load 270kg Elastic Polyurethane Wheel
Description:
This heavy-duty castor with full braking can stop rotating direction and wheels during braking, and the handcart or equi···
Technical data
Wheel diameter
100
Overall height
130
Load capacity
270
If you are interested in this castor, send email us.Stock available, can be sent within 24 hours.We'll give you some discounts.
Select Another Housing

Description:

This heavy-duty castor with full braking can stop rotating direction and wheels during braking, and the handcart or equipment will come to a complete stop. No matter which direction you push, the total brake will be under your feet, and you can easily apply the brake. We have conducted many studies on its braking ability to ensure that the brake can quickly and stably stop the handcart or equipment when in use. The wheels are made of elastic polyurethane, with high load-bearing capacity and low rolling resistance; The wheel core is made of die-cast aluminum, which maintains the high load capacity of the castors and reduces their weight. The low rolling resistance makes it very easy for the cart or equipment to push. They are also suitable for all terrain roads and are your perfect choice.

Contact us now to obtain a discounted quotation, support low minimum order quantity orders, have stock available for quick shipment, and support consignment. The castors are stored in our warehouse, and when you need to deliver, we will send them out.

Polyurethane castors have high load capacity, low rolling resistance and good elasticity.If durability is required, choose polyurethane castors.

The tread of polyurethane castors is a high-quality liquid pouring polyurethane, which is combined with aluminum core or iron core. The solid combination contributes to excellent rolling performance.

In addition, these wheels are non-marking and protect floors. Our premium purethane provides longer service life, better wear and tear characteristics, and rejects floor debris.

The castor bracket is made of stamped steel and galvanized. The turntable support with double balls ensures smooth rotation without jamming.


Housing bracket

Fork made of pressed steel, Zinc-plated

Turning plate bracket

Swivel head with double ball race and sealing, double balls ensure excellent rotational maneuverability

Wheel tread

Polyurethane tread, Shore A 85 tread

Wheel centre body

Aluminum wheel centre

Rolling action

Two ball bearing


L&K Rollen is a company specializing in the supply of heavy-duty castors, offering cost-effective options, discounted prices, and high quality. Contact us now to obtain discounted prices.

Technical data

Castor Number

WAPB100H40UHDX

Wheel diameter

100 mm

Overall height

130 mm

Load capacity

270 kg

Wheel width

40 mm

Size of Plate

105x80 mm

Plate hole centres

80x60 mm

Plate hole

11x9 mm

Offset

40 mm

Speed

4km/H

Temperature

-20 to +70℃

Standard

EN 12532

Housing

Total Lock Castors
